Me Thiab Hnyav -Lub Luag Haujlwm Rough Terrain Forklifts
Txhua qhov ntau suav nrog ntau tus qauv, txhua qhov muab cov yam ntxwv tshwj xeeb kom haum rau ntau yam kev xav tau.
Cov kev xaiv compact yog tshwj xeeb tshaj yog zoo - haum rau kev khiav hauj lwm nyob rau hauv ib puag ncig ua hauj lwm nruj los yog txwv qhov chaw.
Tag nrho cov struts forklift Specifications
Dab tsi yog Rough Terrain Forklift?
Lub forklift yog ib hom khoom siv tuav cov cuab yeej tshwj xeeb uas tsim los rau kev taw qhia thiab ua haujlwm zoo ntawm qhov chaw nyuaj xws li av nkos, pob zeb, tsis sib xws, lossis cov chaw tsim kho rugged. Tsim los rau kev ruaj khov thiab kev ntseeg siab, lub forklift no ua tau zoo hauv kev tswj hwm kev ua haujlwm siab txawm tias nyob rau hauv qhov xav tau thiab hnyav ib puag ncig.
Noelift Rough Terrain Forklift Qhov Zoo
Noelift cov av nkos forklifts yog tsim los daws cov cheeb tsam uas tus qauv forklifts tsis tuaj yeem kov. Lawv cov yam ntxwv tshwj xeeb muaj xws li:
Exceptional Climbing Capability- Yooj yim tswj inclines ntxhab thiab cov struts nyuaj.
Txhim kho av Clearance- Tiv thaiv lub chassis thiab ua kom muaj kev sib haum xeeb ntawm kev sib tw.
Muaj zog Powertrain- Muab kev txhim khu kev qha, txawm tias nyob rau hauv qhov siab tshaj plaws load.
Heavy-Lub luag haujlwm tawm-Txoj Kev Tsheb- Engineered kom pom kev tuav ntawm qhov tsis sib xws thiab rugged.
Me Rough Terrain Forklift - Compact Tseem Muaj Zog
Thaum qhov chaw txwv tsis pub-xws li hauv cov liaj teb, warehouses, los yog cov chaw tsim kho me me- ib lub forklift me me muaj cov tshuaj zoo meej. Nrog rau kev tsim compact thiab tshwj xeeb maneuverability, nws muab tag nrho cov txiaj ntsig ntawm lub forklift struts thaum haum rau hauv qhov chaw nruj, ua rau nws zoo tagnrho rau ntau yam nqa thiab thauj cov dej num.
Ntau- Lub Hom Phiaj Ua Haujlwm Muaj peev xwm
Los ntawm kev txav cov khoom hnyav mus rau kev thauj khoom thiab tshem tawm cov thawv, los ntawm kev tuav cov ntoo mus rau cov khoom siv pov tseg, ib qho av ntxhib forklift tuaj yeem ua txhua yam.
Compatible attachments muaj xws li:
- Fork positioners
- Lub thoob
- Tilting carriages
- Side shifters (integrated los yog nuv-on)
- Los ntawm kev hloov cov ntawv txuas, ib lub forklift tuaj yeem ua ntau yam haujlwm, ua kom cov khoom tsim tau thiab txo cov nqi khoom siv.
Kev siv dav dav
Terrain forklifts yog dav siv hauv:
- Kev tsim kho- Tsim cov chaw, cov phiaj xwm infrastructure
- Ua liaj ua teb- Kev ua lag luam ua teb, ua liaj ua teb logistics
- Kev lag luam kev lag luam- Sawmills, automotive recycling, mining
- Public Works & Logistics- Kev thauj khoom sab nraud, tawm - kev tuav cov khoom siv
Vim li cas thiaj xaiv Noelift Terrain Forklifts?
Los ntawm cov qauv me me ntawm cov qauv forklift rau qhov chaw me me mus rau qhov hnyav - lub luag haujlwm tag nrho - struts forklifts rau qhov chaw nyuaj tshaj plaws, Noelift xa cov cav tov nrog cov nqi them nqi, kev nyab xeeb siab tshaj, thiab kev lag luam - ua kev ntseeg siab. Txawm koj qhov struts, peb muaj lub forklift kom phim koj cov kev xav tau.
Specification parameters
| Qauv | FD25-S | FD30-S | FD35-S | FD40-S | ||||
| TSEEM CEEB | Hwj chim | DIESEL | ||||||
| CAPACITY | kg | 2500 | 3000 | 3500 | 4000 | |||
| LOAD CENTER | mm | 500 | 500 | 500 | 500 | |||
| LFT HEEV | h | mm | 3000 | 3000 | 3000 | 3000 | ||
| MAST TLT ANGLE | F/R | Deg | 8/12 | 8/12 | 8/12 | 8/12 | ||
| MIN. TUA | Ua | mm | 2910 | 2910 | 2910 | 2960 | ||
| RADIUS | ||||||||
| QHOV CHAW UA HAUJ LWM | MAST | mm | 250 | 250 | 250 | 250 | ||
| FRAME | mm | 310 | 310 | 310 | 355 | |||
| HAIV NEEG | h3 | mm | 2220 | 2220 | 2220 | 2265 | ||
| TAWS HEIGHT | ||||||||
| Pem hauv ntej LOAD DISTANCE | mm | 450 | 450 | 450 | 490 | |||
| Kev ua tau zoo | TXOJ CAI TSHIAB | LOAD | km/h | 22 | 22 | 22 | 22 | |
| LFT SPEED | LOAD | mm/s | 450 | 440 | 420 | 420 | ||
| MAX. | LOAD | % | 16 | 16 | 16 | 16 | ||
| GRADEABILITY | ||||||||
| DEMENSION | TAG NRHO LENGTH | TSIS TAU | L2 | mm | 2960 | 2960 | 2960 | 3000 |
| FORK | ||||||||
| TOTALWIDTH | b | mm | 1550 | 1550 | 1550 | 1650 | ||
| MAXHEIGHT | h4 | mm | 4350 | 4350 | 4350 | 4350 | ||
| MAST HEIGHT | h1 | mm | 2230 | 2230 | 2230 | 2300 | ||
| CHASSIS | TIRE | Pem hauv ntej | 12-16.5-14 dr hab | 12-16.5-14 dr hab | 12-16.5-14 dr hab | 14-17.5-16 dr hab | ||
| REAR | 27 × 10.5-15 hli | 27 × 10.5-15 hli | 27 × 10.5-15 hli | 10-16.5-12 dr hab | ||||
| WHEELBASE | L3 | mm | 1850 | 1850 | 1850 | 1850 | ||
| WHEELTREAD | F/R | mm | 1250/1205 | 1250/1205 | 1250/1205 | 1300/1205 | ||
| KEV PAB CUAM | TSIS TAU | Kg | 4650 | 4800 | 4950 | 5200 | ||
| LOAD | ||||||||
| Qauv | FD25-F | FD30-F | FD35-F | FD40-F | ||||
| HARACTEISTICs | Hwj chim | DIESEL | ||||||
| CAPACITY | kg | 2500 | 3000 | 3500 | 4000 | |||
| LOAD CENTER | mm | 500 | 500 | 500 | 500 | |||
| LIFT HOM | h | mm | 3000 | 3000 | 3000 | 3000 | ||
| MIN.TWS RADIUS | Ua | mm | 3120 | 3120 | 3120 | 3120 | ||
| Kev ua tau zoo | MAX.SIB NTAUS | LOAD | km/h | 20 | 20 | 20 | 20 | |
| MAXLIFTING SPEED | LOAD | mm/s | 530 | 530 | 480 | 480 | ||
| MAX.GRADEABILITY | LOAD | % | 30 | 30 | 30 | 30 | ||
| DEMENSION | Nrog FORK | L1+L2 | mm | 4135 | 4135 | 4135 | 4135 | |
| TAG NRHO LENGTH | ||||||||
| TSIS TXAUS SIAB | h1 | mm | 3065 | 3065 | 3065 | 3065 | ||
| TOTALWIDTH | b | mm | 1450 | 1600 | 1600 | 1600 | ||
| MAXHEIGHT | h4 | mm | 4350 | 4350 | 4350 | 4350 | ||
| MAST HEIGHT | h1 | mm | 2235 | 2235 | 2235 | 2280 | ||
| HASSIS | Pem hauv ntej | 14-17.5-14 dr hab | 14-17.5-14 dr hab | 14-17.5-14 dr hab | 14-17.5-14 dr hab | |||
| TIRE | ||||||||
| REAR | 10.0/75-15.3 | 10.0/75-15.3 | 10.0/75-15.3 | 10.0/75-15.3 | ||||
| WHEELBASE | L3 | mm | 1880 | 1880 | 1880 | 1880 | ||
| KEV PAB CUAM | TSIS TAU | Kg | 5050 | 5250 | 5545 | 5800 | ||
| LOAD | ||||||||
Cov khoom pov thawj
FAQ
Q1. Koj cov nqe lus them nqi yog dab tsi?
A: T / T 30% tso nyiaj, thiab 70% ua ntej xa khoom. Peb mam li qhia koj cov duab ntawm cov khoom thiab pob khoom
ua ntej koj them qhov nyiaj tshuav.
Q2. Koj cov nqe lus ntawm kev xa khoom yog dab tsi?
A: EXW, FOB, CFR, CIF.
Q3. Yuav ua li cas txog koj lub sijhawm xa khoom?
A: Feem ntau, nws yuav siv sijhawm 20 hnub tom qab tau txais koj cov nyiaj them ua ntej. Lub sijhawm xa khoom tshwj xeeb nyob ntawm
ntawm cov khoom thiab qhov ntau ntawm koj xaj.
Q4. Koj puas kuaj tag nrho koj cov khoom ua ntej xa khoom?
A: Yog, peb muaj 100% kuaj ua ntej xa khoom
Q5: Koj ua li cas peb ua lag luam ntev -lub sij hawm thiab kev sib raug zoo?
A: 1. Peb khaws cov khoom zoo thiab cov nqi sib tw kom ntseeg tau tias peb cov neeg siv khoom tau txais txiaj ntsig;
2. Peb hwm txhua tus neeg siv khoom raws li peb tus phooj ywg thiab peb ua siab dawb ua lag luam thiab ua phooj ywg nrog lawv,
txawm lawv tuaj qhov twg los.
Peb cov kev pabcuam
1. Ib qho -tso tseg kev daws teeb meem
2. Kev pabcuam OEM muaj
3. 24 teev kev pabcuam tsis nres
4. Taug qab cov khoom rau koj ib zaug txhua ob hnub, txog thaum koj tau txais cov khoom.
5. Thaum lub sij hawm warrarnty, spare qhov chaw xa tuaj nyob rau hauv ib lub lis piam dawb.
Cov ntaub ntawv khoom
NOELIFT EQUIPMENT CO., LTD,ua haujlwm hauv forklift muaj ntau tshaj 10 xyoo. Peb muaj tus neeg sawv cev hauv Malaysia thiab Peru thiab Canada. yog tias koj tab tom nrhiav kev koom tes ntev -, txais tos kom loj hlob nrog peb!
Cim npe nrov: me thiab hnyav-duty ntxhib struts forklifts, Tuam Tshoj me me thiab hnyav-duty ntxhib struts forklifts manufacturers
