Daim Ntawv Roll Electric Stacker

Khoom Piav Qhia Cov Khoom Siv Daim Ntawv Thov 2ton hluav taws xob pallet stacker, TB Series steering wheel tag nrho cov hluav taws xob pallet stacker nrog Daim Ntawv Yob Clamp, rated load peev: 2000kg, nqa qhov siab: 1600-5000mm, siv rau ib lub ntsej muag pallet; Kev thauj khoom thiab thauj khoom, nqa cov khoom los ntawm lub tsev rau khoom mus rau ...

Xa kev nug

Khoom Taw qhia

paper roll electric pallet stacker

Khoom siv

2ton hluav taws xob pallet stacker, TB qauv ntawv yob hluav taws xob pallet stacker.

peb muaj qhov sib txawv qhib ntau yam yob clamp uas haum rau cov kab sib txawv ntawm cov ntawv yob.

Tshuab zoo:

1.Station-tsav steering ua rau kev tswj kom yooj yim dua thiab hloov tau;

2.Qhov tseeb CURTIS tswj qhov system yog qhov tseeb, ruaj khov thiab ua haujlwm zoo;

3. Chaw nres tsheb tsav pedal txais kev tsim kev poob siab;

4.Cov tswj kev sib koom ua ke yog qhov yooj yim thiab zoo nkauj, thiab tag nrho cov haujlwm ua haujlwm tau yooj yim ua tiav los ntawm ib txhais tes;

5.Cov ncej yog lub zog siab steel ncej qauv nrog 5 fulcrums thiab qis nruab nrab ntawm lub ntiajteb txawj nqus;

6.Txhua qhov system txais cov khoom siv tsis muaj dej tsis sib haum;

7.Nws muaj peb lub zog nres: tso nres, rov qab nres thiab nres thaum muaj xwm ceev kom muaj kev nyab xeeb ntawm kev tsav tsheb;

8.Lub rooj zaum thiab caij tsheb yog tsim nyob rau hauv ib lub cev, uas tuaj yeem tiv thaiv cov neeg ua haujlwm zoo dua;

9. Chaw nres tsheb-tsav tus qauv tsheb ceev cia li txo nrog qhov nce ntawm lub kaum sab xis;

10.Nws muaj kev ua haujlwm ntawm kev txo qhov tsis zoo thiab tiv thaiv kev nyab xeeb ntawm cov khoom.

SPECIFICATIONS FOR ELECTRIC PALLET STACKER
Qauv		TB15	TBJ 20
Load peev	kg	1500	2000
Chaw thau khoom	mm	500	500
Ua haujlwm hom		Nws tus kheej propelled	Nws tus kheej propelled
Wheelbase	mm	1208	1208
Nqa qhov siab	mm	1600/2500/3000/3300	1600/2500/3000/3300
Mast txo qhov siab	mm	2150/1785/2035/2185	2150/1785/2035/2185
Fork qhov siab, qis dua	mm	85	85
Zuag qhia tag nrho ntev	mm	2056	2056
Dav dav	mm	850	850
Fork loj (LxWxH)	mm	1150x190x56	1150x190x56
Sab nraum Fork Dav	mm	680	680
Tsav lub cev muaj zog	kws	1.5	1.5
Nqa lub cev muaj zog	kws	2	2
Roj teeb	V/Ah	24/210	24/210
Tag nrho qhov hnyav	kg	1100	1115

Packing & Delivery

Ntim
Ntim Cov Lus Qhia	Pob: nruj pob-Inner Pob: npuas Zaj duab xis ntxiv rau Cardboard ntxiv rau PP Knitted Band ntxiv rau hlau pallet.

delivery

Cov ntawv pov thawj

Peb Qhov Kev Pabcuam

Kev Muag Khoom Ua Ntej

* Kev nug thiab kev pab tswv yim.

* 24 teev kev pabcuam online.

* Saib peb lub Hoobkas.

Kev Pabcuam Tomqab Muag

* Kev cob qhia yuav ua li cas rau nruab lub tshuab, kev cob qhia siv lub tshuab.

* Cov engineers muaj rau kev pabcuam tshuab txawv teb chaws.
